IFM AC505S AS-Interface
신제품
재고 있음2 단위즉시 배송 가능
99,99$
AS-Interface Module
IFM AC505S AS-Interface module with 4 digital inputs, 2 digital outputs, and 2 local outputs, designed for AS-i Safety at Work with DIN rail housing and IP67 protection.
방대한 재고
글로벌 배송
전문 지원
품질 보장
IFM AC505S AS-Interface
The IFM AC505S is a high-quality AS-Interface module designed for industrial automation and safety applications. Built for DIN rail mounting, it provides reliable communication, efficient input/output handling, and durable performance under demanding conditions.
Manufacturer: IFM
Type: AS-Interface
Model: AC505S
Code: E AA 1406
Ref No.: 65843
| Configuration | 4SI 2DO T 2LO (4 digital inputs, 2 digital outputs, 2 local outputs) |
| Design | Housing for DIN rail mounting |
| Application | AS-i Safety at Work |
| Operating Voltage | 26.5 / 31.6 VDC |
| Max. Current Consumption from AS-i | 280 mA |
| Number of Digital Inputs | 2 |
| Input Circuit of Digital Inputs | PNP/NPN |
| Sensor Supply of the Inputs | AS-i |
| Power Supply | 18 / 30 V DC |
| Max. Total Current Rating of Inputs | 200 mA |
| Ambient Temperature | -25 / 55 °C |
| Protection Class | IP 67 |
