IFM ID9922 Inductive Sensor
신제품
재고 있음18 단위즉시 배송 가능
58,88$
Inductive Sensor
The IFM ID9922 inductive sensor provides reliable non-contact metal detection up to 50 mm. Operating on 10“55 V DC with PNP/NPN output and IP67 protection, it™s ideal for industrial automation and harsh environments.AutomationContactDetectionID9922IDC2050BARKG/UP/USifmInductiveIndustrialIP67MetalNonNPNPNPProximitySensor
방대한 재고
글로벌 배송
전문 지원
품질 보장
IFM ID9922 Inductive Sensor
The IFM ID9922 is a durable inductive proximity sensor engineered for precise non-contact detection in industrial automation systems. With a robust brass nickel-plated housing and IP67 protection, it provides reliable sensing performance in demanding environments, offering long service life and high repeat accuracy.
Manufacturer: IFM
Type: Inductive Sensor
Part No.: ID9922
MRN: IDC2050BARKG/UP/US
| Sensing Range | 50 mm |
| Real Sensing Range | 50 ± 10% mm |
| Operating Distance | 0 / 40.5 mm |
| Operating Voltage | 10 / 55 V DC |
| Voltage Drop (max.) | 4.6 V |
| Switching Output Current | 400 mA DC |
| Electrical Design | PNP / NPN |
| Switching Frequency | 90 Hz |
| Output Function | Normally Open |
| Connector Type | M12 Connector, 4-pin |
| Protection Class | II |
| Enclosure Rating | IP67 |
| Housing | Rectangular |
| Ambient Operating Temperature | -25 / 70°C |
| Dimensions | 92 x 80 x 40 mm |
| Material | Brass nickel-plated; PPE |
| Mounting | Flush mountable |
