IFM IFS286 Inductive Sensor
IFM Inductive Sensor IFS286
The IFM IFS286 Inductive Sensor, part number IFK3010-BPKG/K1/US-104, is engineered for versatile industrial applications. It offers a consistent sensing range on all metals, a high protection rating for harsh environments, and is resistant to vibration and shock. This sensor is ideal for applications requiring precision and durability.
- Manufacturer: IFM
- Type: Inductive Sensor
- Model: IFS286
- Part No.: IFK3010-BPKG/K1/US-104
- Features:
- Suitable for industrial, mobile, cooling, and lubricating applications
- High protection rating for harsh environments
- Constant sensing range on all metals
- Very high switching frequency
- Vibration and shock resistant
- Operating Voltage: 10…30 V DC
- Current Rating: 100 mA
- Electrical Design: PNP
- Output Function: Normally open
- Sensing Range: 10 mm
- Housing: Threaded type
- Mounting: Non-flush mountable
- Protection: IP65, IP66, IP67, IP68, IP69K
- Correction Factor: Steel: 1, Stainless Steel: 1, Brass: 1, Aluminium: 1, Copper: 1
- Ambient Temperature: -40…85°C
- Dimensions: M12 x 1 / Length = 60 mm
