INA KRE80-PP-A Stud Type Track Roller
신제품
Schaeffler INA KRE80-PP A Stud Type Track Roller
The Schaeffler INA KRE80-PP A Stud Type Track Roller is designed for demanding applications requiring high load capacity and reliable performance. This roller features a durable PP three-stage sealing system, providing effective protection and reducing wear, ensuring smooth operation even under heavy loads.
Manufacturer: Schaeffler INA
Type: STUD TYPE TRACK ROLLER
Model: KRE80-PP A
Basic Load Ratings (Radial):
This track roller is perfect for systems requiring heavy-duty performance, and its high radial load ratings make it ideal for industrial machinery with constant operation demands.
| Outside Diameter (D) | 80 mm |
| Fit Diameter of Roller Stud (d1) | 30 mm |
| Width of the Roller Stud (B) | 100 mm |
| Roller Width (B1) | 37 mm |
| Thread (G) | M30X1.5 |
| Dynamic (Crw) | 38500 N |
| Static (C0rw) | 78000 N |
| Fatigue Load Limit (Curw) | 11200 N |
| Speed on Permanent Grease Lubrication | 1300 rpm |
| Sealing | PP, Three-Stage Sealing by Plastic Axial Plain Washer on Both Sides |
