Intorq BEG-243-555 Half-Wave Rectifier

Name: INTORQ BEG-243-555 HALF-WAVE RECTIFIER
SKU: 1055270
Availability: LimitedAvailability

intorq-BEG-243-555-half-wave-rectifier-(new)

intorq-BEG-243-555-half-wave-rectifier-(new)-1

intorq-BEG-243-555-half-wave-rectifier-(new)-2

신제품

재고 있음2 단위즉시 배송 가능

Intorq BEG243555 반파 정류기 / 모터 브레이크 정류기 산업용 반파 정류기로 모터 제동 응용 분야에 적합합니다. 스프링 적용 브레이크용으로 설계되었으며 최대 555V AC 및 0.75A를 높은 효율과 신뢰성으로 처리합니다.

제조업체

INTORQ

SKU

1055270

카테고리

Brake Rectifiers

상태

신제품

0.75A 555V AC Brake Braking Components dc Half-Wave Industrial Intorq motor Power Rectifier Spring-Applied supply System to

방대한 재고

글로벌 배송

전문 지원

품질 보장

Intorq BEG243555 Half-Wave Rectifier / Motor Brake Rectifier

The Intorq BEG243555 is a high-performance Half-Wave Rectifier / Motor Brake Rectifier designed to supply power to spring-applied brakes from an AC mains connection. It ensures efficient current conversion, providing reliable operation for industrial braking systems.

Key Details:

Manufacturer: Intorq

Type: Half-Wave Rectifier / Motor Brake Rectifier

Model: BEG243555

Part Number: 13046434

The Intorq BEG243555 rectifier is ideal for industrial motor braking applications, ensuring smooth braking performance, reduced wear, and enhanced system efficiency.

Application Area	Current supply for spring-applied brakes from AC mains (normal excitation)
Max. Mains Voltage	555 V AC
Current	0.75 A
Max. Ambient Temperature	80°C
Number of Poles	4
Dimensions	46 x 17.5 x 25 mm
