Kiepe 93.042196.313 Belt Misalignment Switch
신제품
재고 있음1 단위즉시 배송 가능
Misalignment Belt Switch Kiepe KM3576 belt misalignment switch from the HES family featuring pre-alarm actuation, IP65 protection, aluminum housing, and dual SPDT contacts for conveyor monitoring and industrial safety applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
| Manufacture | Kiepe |
| Part No. | 93.042196.313 |
| Suited for | Control units and systems in accordance with DIIN EN 60204 |
| Rated voltage Ue | 5 … 36 V DC |
| Rated insulation voltage Ui | 250 V |
| Rated impulse withstand voltage Uimp | 2.5 kV |
| Conventional thermal current Ith | 6 A |
| Type of actuation | Pre-alarm bidirectional |
| Enclosure material | Aluminum GK-AlSi 12 |
| Mounting | 2 slotted holes for M8-screws |
| Switching system | 2 changeover contacts (SPDT with snap action) |
| Cable entry | Threaded holes 2x M25x1,5 with each 1x screwed cable gland: sealing area Ø?11mm to Ø?16mm; 1x dummy screw |
| Switching Ratings | AC-15: 230 V; 1.5 A--DC-13: 60 V; 0.5 A-DC-13: 24 V; 2 A |
| Protection degree | IP65 |
| Permissible ambient temperature | -25 … +70°C |
| Dimensions | 177 x 110 x 98 mm |
| Condition | New |
| SKU | 1043074 |
| Weight | 1,88 |
