KRAUS & NAIMER KG64 MAIN SWITCH
중고
재고 있음1 단위즉시 배송 가능
Main Switch
Durable KRAUS&NAIMER KG64 main switch with 3-pole design, 63 A thermal current, IP66 protection, and 690 V insulation voltage for industrial safety.
방대한 재고
글로벌 배송
전문 지원
품질 보장
KRAUS&NAIMER KG64 Main Switch
The KRAUS&NAIMER KG64 is a robust main switch designed for reliable switching and disconnection in industrial environments. With a compact size and durable construction, it provides high performance and safety under demanding conditions.
Manufacturer: KRAUS&NAIMER
Type: Main Switch
Model: KG64
Rated Operational Power AC-3:
| Size | S0 |
| Function | Switch / Switch Disconnector |
| Rated Insulation Voltage | 690 V AC/DC |
| Rated Thermal Current | 63 A |
| 220 - 240 V | 11 kW |
| 380 - 440 V | 18.50 kW |
| 500 - 500 V | 22 kW |
| 660 - 690 V | 15 kW |
| Rated Impulse Voltage Uimp | 6 kV |
| Poles No. | 3-Pole |
| Protection Class | IP66 |
| Ambient Temperature | 0 / 40 °C |
| Dimensions | 64 x 64 mm |
