Motion Control Rotary Encoders

Lika I58-L-1024ZCU110RL2,5C/S367 Incremental Encoder

Name: LIKA I58-L-1024ZCU110RL2,5C/S367 INCREMENTAL ENCODER
Brand: LIKA
SKU: 1008769
Availability: LimitedAvailability

lika-i58-l-1024zcu110rl2-5c_s367-incremental-encoderused

lika-i58-l-1024zcu110rl2-5c_s367-incremental-encoderused-1

lika-i58-l-1024zcu110rl2-5c_s367-incremental-encoderused-2

중고

재고 있음2 단위즉시 배송 가능

증분형 엔코더 Lika I58-L-1024ZCU110RL2,5C/S367는 1024 PPR 해상도, 스테인리스 스틸 샤프트 및 방사형 출력이 있는 견고한 회전 엔코더로 산업 환경의 정밀 모션 시스템에 적합합니다.

제조업체

LIKA

SKU

1008769

카테고리

Rotary Encoders

상태

중고

1024 Control Encoder Incremental Industrial IP64 Lika Motion Output PPR radial Rotary Sensor shaft

방대한 재고

글로벌 배송

전문 지원

품질 보장

LIKA I58-L-1024ZCU110RL2,5C/S367 INCREMENTAL ENCODER

The Lika I58-L-1024ZCU110RL2,5C/S367 is a high-precision incremental encoder designed for reliable rotary motion control in demanding industrial environments. With stainless steel shaft construction and IP64 protection, it offers robust performance with 1024 PPR resolution and a wide operational temperature range.

Manufacturer: Lika

Type: Incremental Encoder

Model: I58-L-1024ZCU110RL2,5C/S367

Part No.: 004000812

Shaft Loading (Axial/Radial)	100 N max.
Shaft Rotational Speed	6000 rpm typical / 12000 rpm temporary
Shaft Diameter	10 mm
Shaft	Stainless steel, non-magnetic - UNI EN 4305
Resolution	1024 PPR
Counting Frequency	300 kHz max
Connection Position	Radial
Operating Temperature	-25 / +85 °C
Degree of Protection	IP64
