Sensors & Measurement Sensors

Micro Detectors AM1/AP-2H3W Cylindrical Inductive Sensor

Name: MICRO DETECTORS AM1/AP-2H3W CYLINDRICAL INDUCTIVE SENSOR
SKU: 1043651
Price: 50.00 USD
Availability: InStock

micro-detectors-AM1_AP-2H3W-cylindrical-inductive-sensor-(new)

micro-detectors-AM1_AP-2H3W-cylindrical-inductive-sensor-(new)-1

신제품

재고 있음4 단위즉시 배송 가능

50,00$

제조사: Micro Detectors 유형: 원통형 유도 센서 모델: AM1/AP2H3W 시리즈: AM

제조업체

MICRO DETECTORS

SKU

1043651

카테고리

Sensors

상태

신제품

Cylindrical Detectors Inductive MD Micro NO Other PNP Proximity Sensor Switch

방대한 재고

글로벌 배송

전문 지원

품질 보장

Manufacture: Micro Detectors
Type: Cylindrical Inductive Sensor
Model: AM1/AP2H3W
Series: AM

Sensing Distance: 4 mm
Ripple: ≤ 10 %
Switching Frequency: 2 KHz
Operating Voltage: 10 … 30 VDC
No-Load supply current: 10 mA
Output current: 200 mA
Tightening Torque: 10 Nm
Electrical Design: PNP
Switching output: 1 Normally open
Protection Class: IP67
LEDs: Yellow
Operating Temperature: -25 … 70°C
Plug Connection: M12 plug cable exit 2 m PVC
Housing material: nickel-plated brass

사양	가치
Weight	0,04 kg
Condition	New
Max. Sensing Range [mm]	4
Manufacturer	MICRO DETECTORS
Type of Product	Cylindrical Inductive sensor
Nominal Voltage [DC]	24 V
Contact	1 NO
Current [A]	0.2
Torque [Nm]	10
Shelf No.	240420
Diameter [mm]	M12
Material	nickel-plated brass
Connection	M12 plug cable exit 2 m PVC
