Contactor Relay

The Moeller DILER-40 is a compact contactor relay with 4 NO contacts, 10 A current rating, and IP20 protection. Operating at 230“240 V AC, it is ideal for switching tasks in industrial automation systems.

제조업체
MOELLER
SKU
1075472
상태
신제품
공유
방대한 재고
글로벌 배송
전문 지원
품질 보장

Moeller DILER-40 Contactor Relay

The Moeller DILER-40 Contactor Relay is designed for reliable switching and control in electrical systems. Built for high-performance industrial use, it supports up to 10 A operation current and features 4 normally open (NO) contacts with IP20 protection, making it ideal for automation and control panels.

Manufacturer: Moeller

Type: Contactor Relay

Model: DILER-40

Rated Control Supply Voltage230 to 240 V AC
Frequency50 to 60 Hz
Rated Operation Current10 A
Operating Voltage500 V @ 1.5 A / 380“415 V @ 3 A / 220“240 V @ 6 A
Contacts4 Normally Open (NO)
Tightening Torque1.2 Nm
Wire Gauge (AWG)18 to 14
Rated Impulse Withstand Voltage (Uimp)6000 V AC
Protection ClassIP 20
Operating Temperature-25 to 50 °C
Dimensions (W x H x D)45 x 58 x 52 mm
