Murr 57101 Power Module
신제품
재고 있음3 단위즉시 배송 가능
Cube20S PROFIBUS DP Bus Node
MURR Elektronik Cube20S PROFIBUS DP Bus Node BN-DP with integrated power module, 24 V supply, PROFINET IO interface, dual RJ45 connection, and expandability up to 64 modules.AutomationBN-DPBUSconnectionCube20SDPElektronikexpansionIndustrialIOModularModuleMurrNodePowerProfibusProfinetRJ45
방대한 재고
글로벌 배송
전문 지원
품질 보장
MURR Elektronik Cube20S PROFIBUS DP Bus Node
The MURR Elektronik Cube20S PROFIBUS DP Bus Node with integrated power module offers efficient communication and power distribution for modular automation systems. It ensures reliable operation, easy connectivity, and supports extensive expandability for industrial applications.
Manufacturer: MURR Elektronik
Type: Cube20S PROFIBUS DP Bus Node / Bus Node Including Power Module
Model: BN-DP (Bus Node “ Profibus DP)
Art No.: 57101
Codes: A288 / 00291013
REF NO.: 4A2S8-2.31-0.02
| Supply Voltage (Nominal Value) | 24 V |
| Supply Voltage (Admissible Range) | 20.4...28.8 V |
| Power Consumption (Idle) | 95 mA |
| Power Consumption (Nominal Value) | 0.95 A |
| Switch-On Current | 3.9 A |
| I2t | 0.14 A2s |
| Current Supply On Backplane Bus | 3 A |
| Current Supply Load Supply | 10 A |
| Power Dissipation | 3 W |
| Connection - Fieldbus | PROFINET IO |
| Physics | Ethernet 100 MBit |
| Connection Type | 2 x RJ45 |
| I/O Expandability | Supports up to 64 Cube20S expansion modules per bus node |
| Temperature Range | 0 °C / +60 °C |
