Pepperl+Fuchs NBN3-F25-E8-0,14 Inductive Sensor
유도 센서 Pepperl+Fuchs NBN3-F25-E8-0,14 유도 센서는 3mm 감지 범위, PNP 스위칭 및 IP67 보호 기능을 제공합니다. 정밀하고 신뢰할 수 있는 산업 자동화용으로 설계되었습니다.
Pepperl+Fuchs NBN3-F25-E8-0,14 Inductive Sensor
The Pepperl+Fuchs NBN3-F25-E8-0,14 Inductive Sensor is a reliable and high-performance proximity sensor designed for industrial automation and detection applications. With flush mountable installation and IP67 protection, it ensures precise and durable operation in demanding environments.
Manufacturer: Pepperl+Fuchs
Type: Inductive Sensor
Model: NBN3-F25-E8-0,14
Designed for precision and durability, the Pepperl+Fuchs NBN3-F25-E8-0,14 sensor is ideal for automation systems requiring reliable inductive sensing technology.
| Rated Operating Distance (Sn) | 3 mm |
| Operating Voltage (UB) | 10 ... 30 V DC |
| Operating Current | 0 ... 200 mA |
| Short-Circuit Protection | Pulsing |
| Installation | Flush mountable |
| No-Load Supply Current | 25 mA |
| Switching Element Function | PNP |
| Connection Type | Cable PVC, 180 mm |
| Tightening Torque, Fastening Screws | M5 x 25: 2.7 Nm |
| Degree of Protection | IP67 |
| Ambient Temperature | -25 ... 70 °C |
