Phoenix Contact PSR-SCF-24UC/URM/4X1/2X2 Coupling Relay
신제품
Manufacturer: Phoenix Contact
Type: Coupling Relay
Model: PSR-SCF-24UC/URM/4X1/2X2
Part No.: 2981444
Rated control circuit supply voltage US: 24 V AC/DC -20 % / +10 %
Rated control supply current IS: typ. 52 mA
Response Time: Typ. 10 ms
Contact type: 4 N/O, 2 N/C contacts
Switching Frequency: 0.5 Hz
Switching Output voltage: 5 V AC/DC … 230 V AC/DC
Inrush current: 10 mA … 6 A
Switching Capacity: min. 50 mW
Connection method: Screw connection
Operating Temp.: -20 … 55°C
Degree of protection: IP20
Dimensions: 111 x 40 x 56 mm
