Rexroth R036040000 Compact Linear Module
신제품
재고 있음4 단위즉시 배송 가능
Compact Linear Module Bosch Rexroth compact linear module with ball screw assembly, engineered for high-precision positioning, smooth linear motion, and heavy-duty industrial automation applications.
ActuatorassemblyAutomationBallBoschCompactComponentsControlDutyGuideHeavyIndustrialLinearModuleMotionPositioningPrecisionRexrothscrewSystem
방대한 재고
글로벌 배송
전문 지원
품질 보장
| MNR | R036040000 |
| Serial No. | 81729660 |
| CS No. | 0007816186 000010 2 |
| FD | 375 |
| Code | IT10 |
| Size | 110 |
| Linear axes variant | Ball screw assembly |
| Stroke | Smax. 451 mm |
| Lead of the screw | 16 mm/U (distance traveled per 1 revolution) |
| linear velocity | max. 1.23 m/s |
| Acceleration rate | max. 50 m/s² |
| linear Speed | max. 1.22 m/s |
| Maximum drive torque | max. 2.11 Nm |
| Drive direction | CCW (Counter Clockwise) |
| Gear ratio | 1.50 |
| Fz1 | max. 12000 N |
| Fz2 | max. 12000 N |
| Fy | max. 5650 N |
| Dynamic Load Capacity | guideway Cgw: 32035 N, fixed bearing Cfb: 13400 N |
| Profiled rail system A | 110 mm |
| Profiled rail system H1 | 66 mm |
| Profiled rail system H2 | 49 mm |
| Profiled rail system H | 50 mm |
| Condition | New |
| Stock Key | JO-004 |
| SKU | 1097552 |
| Weight | 7,84 |
