Schneider Pacdrive C400/A8/1/1/1/00 Servo Controller Drive

Manufacturer: SCHNEIDER ELAU
Type: Servo Controller Drive
Model: PacDrive C400A811100
Part No.: 13130261001 / 97731300102211

Range: PacDrive C400 A8
Supply Voltage: 24 V DC
Rated Current: 2.5 / 3.5 A
Power Consumption Max.: 85 W
Digital Input (DI) No.: 20 (24 V DC, 5 mA)
Digital Output (DO) No.: 16 (24 V DC, 250 mA)
Analog Input (AI) No.: 18 24 V DC, 5 mA
Interface: RS232 / RS485 / PROFIBUS DP
Protection Class: IP20
Temperature: 5 … 45 °C
Dimensions: 296 x 103.2 x 260 mm
