SEW EV1S Incremental Encoder
중고
재고 있음2 단위즉시 배송 가능
275,00$
증분 인코더 Sew Eurodrive ROD 486 1024 30B10-2B / EV1S 증분 인코더는 1024 PPR 해상도, 6mm 실축, 산업용 모션 제어를 위한 IP56 보호 기능을 갖추고 있습니다.
방대한 재고
글로벌 배송
전문 지원
품질 보장
Sew Eurodrive ROD 486 1024 30B10-2B / EV1S Incremental Encoder
The Sew Eurodrive ROD 486 1024 30B10-2B / EV1S Incremental Encoder is designed for precise motion control in industrial applications. Built for asynchronous AC motors, this encoder offers a high-resolution 1024 PPR output, ensuring accurate speed and position feedback.
Manufacturer: Sew Eurodrive
Type: Incremental Encoder
Model: ROD 486 1024 30B10-2B / EV1S
Part No.: 339 184-01
Serial No.: 10887630
| For Motors | Asynchronous AC motors DT/DV/D 71 / 225 |
| Shaft Design | Solid Shaft |
| Shaft Diameter | 6 mm |
| Voltage Supply | 10 / 30 VDC |
| Resolution | 1024 Pulse per Revolution (PPR) |
| Max. Current Consumption | 160 mA |
| Output Signal | Sin/Cos |
| Max. Pulse Frequency | 120 kHz |
| Output Connection | Terminal Box |
| Protection Class | IP56 |
| Temperature | -25 / 60°C |
