Sick ACM60B-S1KE13X06 Absolute Encoder
중고
재고 있음1 단위즉시 배송 가능
299,99$
ABSOLUTE ENCODER
Sick ACM60B-S1KE13X06 absolute encoder with 10,485 steps, 64 revolutions, 18“36 V DC, 4“20 mA, M12 5-pin connection, and solid shaft servo flange design.144818“36V4“20mA6045312AbsoluteACM60B-S1KE13X06AutomationdcEncoderFlangeHighIndustrialPrecisionServoshaftSickSolid
방대한 재고
글로벌 배송
전문 지원
품질 보장
Sick ACM60B-S1KE13X06 Absolute Encoder
The Sick ACM60B-S1KE13X06 is a high-precision absolute encoder designed for reliable performance in automation and motion control systems. Featuring solid shaft design, servo flange mounting, and adjustable code sequence, it ensures accurate feedback and durability under industrial conditions.
Manufacturer: Sick
Type: Absolute Encoder
Model: ACM60B-S1KE13X06
ID No.: 6045312
yyww: 1448
Serial No.: 14323270
| Number of Steps per Revolution (Max. Resolution) | 10485 |
| Number of Revolutions | 64 (6 bit) |
| Max. Resolution | 10,485 x 64 (6 bit) |
| Voltage | 18 to 36 V DC |
| Current | 4 to 20 mA |
| Code Sequence Parameter | Adjustable, CW (clockwise) |
| Connection Type | Male connector, M12, 5-pin, radial |
| Electrical Wiring | 3-wire or 4-wire |
| Mechanical Design | Solid shaft, Servo flange |
| Shaft Diameter | 6 mm |
| Shaft Length | 10 mm |
| Shaft Characteristics | With flat |
| Operating Temperature Range | -30 °C to +80 °C |
