Sick YG2A14-050VB3XLEAX Sensor-Actuator Cable
신제품
재고 있음1 단위즉시 배송 가능
Sensor-Actuator Cable SICK sensor-actuator cable featuring a 5 m 4-wire PVC cable, angled M12 4-pin A-coded female connector, flying leads, and IP65 / IP66K / IP67 enclosure protection for industrial automation applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
| Part No. | 2095897 |
| Connection type head A | Female connector, M12, 4-pin, angled, A-coded |
| Connection type head B | Flying leads |
| Nominal voltage, cable | 300 V AC |
| Test voltage, cable | 2,000 V AC |
| Insulation voltage | 30 V AC/DC |
| Reference voltage | 250 V AC, 250 V DC |
| Rated impulse voltage | 2.5 kV |
| Current loading | 4 A |
| Locking plug connector | Screw connection |
| Connector material | TPU |
| Locking nut material | Zinc die-cast, nickel-plated |
| Seal material | FKM |
| Tightening torque | 0.6 Nm |
| Width across flats | 13 |
| Cable | 5 m, 4-wire, PVC |
| Jacket material | PVC |
| Cable diameter | 5 mm |
| Conductor cross section | 0.34 mm² |
| Signal type | Sensor/actuator cable |
| Application | Uncontaminated zones, Zones with chemicals |
| Enclosure rating | IP65 / IP66K / IP67 |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1098241 |
| Weight | 0,21 |
