SICK WL45-N260 Photoelectric Sensor
신제품
재고 있음3 단위즉시 배송 가능
Photoelectric Sensor SICK WL45-N260 retro-reflective photoelectric sensor with visible red LED light, NPN complementary output, sensing range up to 55 m, and adjustable switching functions for industrial automation applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
| Part No. | 1008669 |
| Ref No | 2113 |
| Supply voltage UB | 10 V DC ... 60 V DC |
| Functional principle | Photoelectric retro-reflective sensor Functional principle detail: With minimum distance to reflector (dual lens system) |
| Dimensions (W x H x D) | 60 mm x 105 mm x 105 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 1 m ... 55 m |
| Sensing range | 1 m ... 45 m |
| Type of light | Visible red light |
| Light source | LED |
| Light spot size (distance) | dia 230 mm (16 m) |
| Adjustment | Potentiometer |
| Ripple | 5 Vpp |
| Current consumption | 50 mA |
| Switching output | NPN |
| Output function | Complementary |
| Switching mode | Light/dark switching |
| Output current Imax. | 200 mA |
| Response time | 1.2 ms |
| Switching frequency | 400 Hz |
| Ambient operating temperature | –25 °C ... +55 °C |
| Time functions | Switch-on delay, Off delay ,ON and OFF delay |
| Stock Key | CON-003 |
| Condition | New |
| SKU | 1099325 |
| Weight | 0,81 |
