Siemens 1FK7034-5AY81-1YY3-Z S70 Servo Motor With Gear
중고
재고 있음4 단위즉시 배송 가능
Servo Motor
SIEMENS 1FK7034-5AY81-1YY3-Z S70 Servo Motor offers a rated speed of 4300 RPM, 0.54 kW power, and is protected with IP65 class. Coupled with the ALPHA SP 075S-MF2-20-1E1-2S planetary gearbox for superior performance and torque handling.0.54075S-MF2-20-1E1-2S1264300AlphaClassGearboxhigh-performanceIndustrialIP65kWmotorNmPlanetaryProtectionrpmServoSPTorque
방대한 재고
글로벌 배송
전문 지원
품질 보장
SIEMENS 1FK7034-5AY81-1YY3-Z S70 Servo Motor
The SIEMENS 1FK7034-5AY81-1YY3-Z S70 Servo Motor offers high precision and reliability for industrial automation. Designed with a rated speed of 4300 RPM and a rated power of 0.54 kW, this motor is ideal for high-performance applications. The motor is coupled with the ALPHA SP 075S-MF2-20-1E1-2S planetary gearbox for enhanced torque and speed capabilities.
Manufacturer: SIEMENS
Type: Servo Motor
Model: 1FK7034-5AY81-1YY3-Z S70
Technical Specifications
- Rated Voltage: 137 VAC
- Rated Speed: 4300 RPM
- Max Speed: 4300 RPM
- Rated Power: 0.54 kW
- Rated Current: 1.6 A
- Protection Class: IP65
- Thermal Class: F
- Attached with: ALPHA SP 075S-MF2-20-1E1-2S PLANETARY GEARBOX
- Stages: 2-stage
- Size: 075
- Ratio: 20
- Max. Torque: 126 Nm
- Speed: 8500 rpm
- Shaft: 22 mm
