Siemens 1LA6 186-6AA61-Z 3 Phase Electric Motor
재고 있음1 단위즉시 배송 가능
3상 전기 모터 Siemens 1LA6186-6AA61-Z는 50Hz에서 15.0 kW, 60Hz에서 18.0 kW를 출력하며, 148 Nm 토크, IP55 보호 등급 및 B5 장착 방식을 갖춘 3상 모터로, 중공업용에 적합합니다.
15kW180L18kW1LA6186-6AA61-Z3400V460V6690VB5DeltaDutyEfficiencyElectricFRHeavyHighIndustrialIP55motorMountingPhasePoleSiemensStar
방대한 재고
글로벌 배송
전문 지원
품질 보장
SIEMENS 1LA6186-6AA61-Z 3 PHASE ELECTRIC MOTOR
The Siemens 1LA6186-6AA61-Z is a robust and energy-efficient 3-phase electric motor engineered for heavy-duty industrial operations. Featuring dual-frequency compatibility and a high protection class, this motor delivers powerful performance and long-term reliability.
Manufacturer: Siemens
Type: 3 Phase Electric Motor
Model: 1LA6186-6AA61-Z
REF NO: 120483/1993
Frame Size: 180L
| Number of Pole | 6 |
| Rated Voltage at 50Hz | 400 / 690 V (Delta/Star) |
| Rated Current at 50Hz | 30 / 17.5 A |
| Rated Torque | 148 Nm |
| Rated Power at 50Hz | 15.0 kW |
| Rated Speed at 50Hz | 970 min»¹ |
| Moment of Inertia | 0.2 J |
| Power Factor | 0.82 |
| Efficiency | 89.0% |
| Rated Voltage at 60Hz | 460 V (Delta) |
| Rated Current at 60Hz | 30.5 A |
| Rated Power at 60Hz | 18.0 kW |
| Rated Speed at 60Hz | 1170 min»¹ |
| Power Factor (60Hz) | 0.82 |
| Mounting Position | B5 |
| Protection Class | IP55 |
| Insulation Class | F |
