Siemens 1PH71072NF020CJ0 Asynchronous Motor
중고
재고 있음1 단위즉시 배송 가능
ASYNCHRONOUS MOTOR
Siemens 1PH71072NF020CJ0 asynchronous motor delivers high performance with 9.0/13.0/9.0 kW power, up to 9000 min»¹ speed, and IP55 protection”ideal for precision industrial systems.
방대한 재고
글로벌 배송
전문 지원
품질 보장
SIEMENS 1PH71072NF020CJ0 ASYNCHRONOUS MOTOR
The Siemens 1PH71072NF020CJ0 is a high-performance asynchronous motor engineered for industrial precision, durability, and flexibility in dynamic operating conditions. With a wide speed range and dual-duty capability (S1/S6), it ensures reliable performance in continuous and cyclic applications. This robust motor is equipped with advanced protection, a high-resolution encoder, and is ideal for integration in systems requiring exacting speed control and operational stability.
Manufacturer: SIEMENS
Type: Asynchronous Motor
Model: 1PH71072NF020CJ0
nr. E: KN62 3510 02 001
Code no: 429
| Rated Current [A] | 23.5/31 |
| Rated Voltage [V] | 336 |
| Rated Power [kW] | 9.0/13.0/9.0 |
| Rated Speed [min»¹] | 1500/1500/6500 |
| Max. Speed [min»¹] | 9000 |
| Frequency [Hz] | 52 |
| Power Factor [cos φ] | 0.8 |
| Mounting Position [IM] | B5 |
| Duty | S1/S6/S1 |
| Encoder | D01 2048 S/R |
| Thermal Class | F |
| Protection Class | IP55/54 |
