Siemens 3RU1136-4DB0 Overload Relay
재고 있음1 단위즉시 배송 가능
제조사: Siemens 유형: 과부하 릴레이 모델: 3RU1136-4DB0
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: Siemens
Type: Overload Relay
Model: 3RU1136-4DB0
Rated insulation voltage Ui: 690 V
Surge voltage resistance rated value: 6 kV
Current: 18 … 25 A
Power loss: for rated value of the current at AC in hot operating state 10.5 W, per pole 3.5 W
Number of auxiliary contacts: 1 Normally open contact, 1 Normally closed
Type of electrical connection: screw-type terminals
Number of poles for main current circuit: 3
Operating Temperature: -20 … +70 °C
Degree of protection: IP20
Type of protection: DMT 98 ATEX G 001
Dimensions: 105 x 55 x 118 mm
