Siemens 3SE5 122-0CA00 Mechanical Safety Switch
신제품
재고 있음4 단위즉시 배송 가능
44,44$
MECHANICAL SAFETY SWITCH
SIEMENS 3SE5122-0CA00 mechanical safety switch features IP66/IP67 protection, 400 V insulation voltage, and 0.05 mm repeat accuracy. Ideal for precise industrial safety control systems.3SE5122-0CA00400V60947-5-1AccuracyCompliantControlDeviceHighIECIndustrialIP66MechanicalSafetySiemensSwitch
방대한 재고
글로벌 배송
전문 지원
품질 보장
SIEMENS 3SE5122-0CA00 MECHANICAL SAFETY SWITCH
The Siemens 3SE5122-0CA00 is a robust mechanical safety switch engineered for industrial safety and precision. Compliant with IEC/EN 60947-5-1 standards, it offers high reliability and protection in demanding environments.
Manufacturer: SIEMENS
Type: Mechanical Safety Switch
Model: 3SE5122-0CA00
Standard: IEC/EN 60947-5-1
| Insulation Voltage (Rated) | 400 V |
| Surge Voltage Resistance (Rated) | 6 kV |
| Protection Class | IP66/IP67 |
| Thermal Current | 10 A |
| Continuous Current (C Characteristic MCB) | 1 A |
| Continuous Current (Quick DIAZED Fuse) | 10 A |
| Continuous Current (DIAZED Fuse Link gG) | 6 A |
| Active Principle | Mechanical |
| Repeat Accuracy | 0.05 mm |
| Minimum Actuating Force | 20 N |
| Sensor Length | 85.7 mm |
| Sensor Width | 56 mm |
| Ambient Temperature (Operation) | -25 to +85 °C |
