Siemens 3SE5232-0BC05 Position Switch
신제품
요청 시 제공 가능
Position Switch
A precision mechanical position switch from the SIEMENS SIRIUS range, designed for reliable position detection, high repeat accuracy, and durable operation in industrial automation applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
SIEMENS SIRIUS 3SE5232-0BC05 Position Switch
A high-precision mechanical position switch from the SIRIUS range, designed for reliable position detection and control in industrial automation environments. This switch is engineered to deliver stable mechanical actuation, high electrical durability, and resistance to harsh operating conditions. Manufacturer: SIEMENS
Product Brand Name: SIRIUS
Type: Position Switch
Product Designation: Mechanical Position Switches
Product Type Designation: 3SE5
MRN: 3SE5232-0BC05
| Rated Insulation Voltage | 400 V |
| Degree Of Pollution | Class 3 |
| Rated Surge Voltage Resistance | 6 kV |
| Protection Class | IP65 |
| Shock Resistance | 30 g / 11 ms (According to IEC 60068-2-27) |
| Thermal Current | 10 A |
| Enclosure Material (Switch Head) | Plastic |
| Reference Code According To IEC 81346-2 | B |
| Continuous Current “ C Characteristic MCB | 1 A (For Short-Circuit Current < 400 A) |
| Continuous Current “ Quick DIAZED Fuse Link | 10 A (For Short-Circuit Current < 400 A) |
| Continuous Current “ DIAZED Fuse Link gG | 6 A |
| Active Principle | Mechanical |
| Repeat Accuracy | 0.05 mm |
| Sensor Length | 75.7 mm |
| Sensor Width | 31 mm |
| Ambient Temperature During Operation | -25 °C to +85 °C |
| Number Of NC Contacts (Auxiliary) | 1 |
| Number Of NO Contacts (Auxiliary) | 1 |
