Siemens 6ES7 155-6AU01-0BN0 Profinet Interface Module
신제품
재고 있음1 단위즉시 배송 가능
PROFINET Interface Module SIEMENS SIMATIC ET 200SP IM 155-6 PN ST interface module with 24 V DC supply, PROFINET communication, and support for up to 256 submodules for industrial automation systems
방대한 재고
글로벌 배송
전문 지원
품질 보장
| Serial No. | C-M7DX9711 |
| Family | SIMATIC ET 200SP |
| Product type designation | IM 155-6 PN ST |
| HW functional status | From FS03 |
| Firmware version | V4.2 |
| Configuration control | via dataset |
| Rated value | 24 V DC |
| permissible range, lower limit | 19.2 V DC |
| permissible range, upper limit | 28.8 V DC |
| Current consumption (rated value) | 450 mA |
| Current consumption | max. 550 mA |
| Inrush current | max. 3.7 A |
| Power loss | 1.9 W |
| Address space per station | max. 512 byte |
| Number of submodules per station | max. 256 |
| Network loading class | 2 |
| Width | 50 mm |
| Height | 117 mm |
| Depth | 74 mm |
| Ambient temperature | (horizontal installation, -30 to 60 °C), (vertical installation, -30 to 50 °C) |
| Condition | New |
| Stock key | CON003 |
| SKU | 1093714 |
| Weight | 0,19 |
