SIEMENS 6SL3210-1KE12-3AF2 Frequency Inverter
신제품
재고 있음1 단위즉시 배송 가능
Compact Frequency Inverter SIEMENS SINAMICS G120C compact frequency inverter with 380–480 V 3-phase input, up to 0.75 kW output, and PROFINET and EtherNet/IP communication for industrial motor control.
방대한 재고
글로벌 배송
전문 지원
품질 보장
| code | S ZVS2100718991 |
| MNR | 6SL3210-1KE12-3AF2 |
| Family | SINAMICS G120C |
| FW | V4.7 SP10 HF3 |
| SN | 4042948668719 |
| Degree of protection | IP20 / UL open type |
| Frame size | FSAA |
| Dimensions | Width 73 mm (2.87 in) Height Depth 173 mm (6.81 in) 160 mm (7.01 in) |
| Compliance with standards | CE marking CE, cUL, UL, KC, EAC, C-Tick (RCM) EMC Directive 2004/108/EC, LowVoltage Directive 2006/95/EC |
| Number of phases, Input | 3 AC |
| Line voltage, Input | 380 ... 480 V +10 % -20 % |
| Line frequency, Input | 47 ... 63 Hz |
| Rated current (LO) , Input | 2.90 A |
| Rated current (HO) , Input | 2.50 A |
| Number of phases, Output | 3 AC |
| Rated voltage, Output | 400V IEC 480V NEC 1) |
| Rated power (LO) , Output | 0.75 kW 1.00 hp |
| Rated power (HO) , Output | 0.55 kW 0.75 hp |
| Rated current (LO) , Output | 2.20 A |
| Rated current (HO) , Output | 1.70 A |
| Rated current (IN) , Output | 2.30 A |
| Max. output current, Output | 3.40 A |
| Pulse frequency, Output | 4 kHz |
| Output frequency for vector control | 0 ... 240 Hz |
| Output frequency for V/f control | 0 ... 550 Hz |
| Overload capability Low Overload (LO) | 150 % |
| base load current IL for | 3 s, followed by 110 % |
| Power factor ? | 0.70 ... 0.85 |
| Offset factor cos f | 0.95 |
| Efficiency ? | 0.97 |
| Sound pressure level (1m) | 49 Db |
| Power loss | 39.0 W |
| Filter class (integrated) | Class A |
| Communication | PROFINET, EtherNet/IP |
| digital inputs Number | 6 |
| Max. inrush current | 15 mA |
| Fail-safe digital inputs Number | 1 |
| Digital outputs Number as relay changeover contact | 1 |
| Output (resistive load) DC | 30 V, 0.5 A |
| Number as transistor | 1 |
| Analog / digital inputs Number | 1 (Differential input) |
| Resolution | 10 bit |
| Switching threshold as digital input | 0?1 4 V 1?0 1.6 V |
| Analog outputs Number | 1 (Non-isolated output) |
| Stock key | CH001 |
| Condition | New |
| SKU | 1100863 |
| Weight | 1,72 |
