Sprecher+Schuh LE2-20-5261 Step Switch
신제품
재고 있음1 단위즉시 배송 가능
49,99$
제조사: Sprecher+Schuh / Breter 유형: 스텝 스위치 모델: LE 2-20-5261 부품 번호: 14.117.152-61
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: Sprecher+Schuh / Breter
Type: Step Switch
Model: LE 2-20-5261
Part No.: 14.117.152-61
Thermal current Ith: 20 A
Rated Insulation Voltage Ui: 690 V AC
Rated Impulse Withstand Voltage Uimp: 6 kV
Switching rating AC22A: 660 V AC, 20 A
Frequency: 50/60 Hz
Standard: IEC 947-3 , VDE 0660
Power Consumption:
4.5 kW (220 V AC)
7.5 kW (380 V AC)
10 kW (500 V AC)
Function Switching angle: 0-1-2-3 (45°)
No. of Poles: 1
No. of Steps: 4
Mounting: Panel Mount
Protection degree: IP20
Operating Temperature: -25 … 60°C
Dimensions: 55 X 55 X 57 mm
