Telemecanique CA4KN22BW3 Control Relay
신제품
재고 있음1 단위즉시 배송 가능
Control Relay
A compact and efficient relay from the TeSys CAK series, designed for precise switching and reliable operation in industrial control applications.2224v2NC2NOAutomationBW3CA4KNCAKcoilComponentControldcDeviceElectricalIndustrialmotorRelayTelemecaniqueTeSys
방대한 재고
글로벌 배송
전문 지원
품질 보장
Telemecanique CA4KN 22 BW3 Control Relay
A compact and reliable control relay designed for high-performance industrial control circuits. Engineered for durability and precise switching, the TeSys CAK series offers excellent electrical endurance and compatibility with automation and protection systems. Manufacturer: Telemecanique
Type: Control Relay
Model: CA4KN 22 BW3
Part No.: 042859
Serial No.: 3389110 / 428599
| Range | TeSys |
| Product Name | TeSys CAK |
| Product Type | Control Relay |
| Device Short Name | CA4K |
| Application | Control Circuit |
| Utilisation Category | DC-13, AC-15 |
| Pole Contact Composition | 2 NO + 2 NC |
| Rated Operational Voltage [Ue] | 690 V / 400 Hz |
| Control Circuit Type | DC Low Consumption |
| Control Circuit Voltage [Uc] | 24 V DC |
| Minimum Switching Voltage | 17 V |
| Minimum Switching Current | 5 mA |
| Non-Overlap Distance | 0.5 mm |
| Insulation Resistance | > 10 MΩ |
| Height | 58 mm |
| Width | 45 mm |
| Depth | 57 mm |
| Standards | IEC 947, NFC 63110, VDE 0660 |
