02C34LM / ULN2004AN Integrated Chip

Type: Integrated Chip
Model: ULN2004AN
Part No.: 02C34LM

Features:
-Seven Darlington’s per package
-Integrated suppression diodes for inductive loads
-Outputs can be paralleled for higher current
-TTL/CMOS/PMOS/DTL compatible inputs
-Input pins placed opposite to output pins to simplify layout
Switching voltage (max): 50 V
Output voltage (max): 50 V
Peak output current: 0.5 A
Delay time (typ): 250 ns
No. of pins: 16
Operating temperature range: -20 … 70°C
