ABB C561.10 Time Relay

ABB TIME RELAY C561.10

The ABB TIME RELAY C561.10 is a high-performance relay designed for industrial and control applications. It offers precise time delay functions, ensuring reliable operation in automated systems. With robust construction, versatile voltage ratings, and a wide operating temperature range, this time relay is ideal for demanding environments where timing accuracy and durability are crucial.

Manufacturer: ABB

Model: C561.10

Part Number: G/010706D08

Type: Time Relay

Key Features:

• Rated Insulated Voltage: 250 V AC
• Rated Power: 2 W
• Rated Operating Current:
  • AC 15 at 230 V / 50 Hz: 3 A
  • DC-13 at 24 V DC: 1 A
  • DC-13 at 230 V DC: 0.1 A
• Enclosure Protection: IP 20
• Tightening Torque: 0.8 to 1.2 Nm
• Wide Ambient Temperature Range: -25 to 60 °C
• Dimensions: 120 x 22.5 x 86 mm

The ABB TIME RELAY C561.10 ensures that critical time-based operations are performed with precision, making it an essential component in automation systems.
