Manufacturer: ACE Controls
Type: HYDRAULIC DAMPER
Model: DVC-32-50-BB-P
Compression Force: 9.5 … 300 lbs
Stroke: 50 mm
L Extended: 240 mm
Operating Temperature: 0 … 65°C
Lifetime Approx.: 250,000 cycles
Diameter Outer Body/ Piston Rod: 32 / 8 mm
Adjustment: Steplessly adjustable
Positive Stop: External positive stops 0.04 into 0.06 in before the end of stroke provided by the customer
Mounting: In any position
Material: Outer body: Coated Aluminium; Piston rod: Hard chrome plated steel; End fittings: Zinc plated steel
Damping Medium: Automatic Transmission Fluid (ATF)
Weight: 0.35 Kg
