Balluff BES M08MG1-PSC60F Inductive Sensor
Used
In stock1 unitReady to ship
Balluff Inductive Sensor BESM08MG1-PSC60F with 6 mm sensing range, 500 Hz switching frequency, and PNP electrical design. Enclosure rated IP67 for reliable industrial performance.
5006BalluffbrassConnectorenclosureFaceFlushFrequencyHousingHzInductiveIndustrialIP67M8mmMountableNonNormallyOpenPBTPNPRangeSensingSensorSensorsSwitching
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Balluff Inductive Sensor BESM08MG1-PSC60F
Balluff Inductive Sensor BESM08MG1-PSC60F is designed to offer reliable detection in industrial applications, ensuring optimal performance with its precise sensing range and robust construction. Below are the key technical specifications:
- Manufacturer: Balluff
- Type: Inductive Sensor
- Model: BESM08MG1-PSC60F
Technical Data:
- Sensing Range: 6 mm
- Assured Operating Distance: 4.8 mm
- Operating Voltage: 10 / 30 V DC
- Switching Frequency: 500 Hz
- Electrical Design: PNP
- Switching Output: Normally Open
- Connector Type: M8
- Enclosure Rating: IP67
- Ambient Operating Temperature: -25 to 70°C
- Diameter, Housing Length: 8, 60 mm
- Housing Material: Brass, Chrome-plated
- Sensing Face Material: PBT
- Mounting: Non Flush Mountable
