Carlo Gavazzi SV 115 724 Level Sensors Amplifier, Conductive

Manufacturer: CARLO GAVAZZI

Type: Level Sensors Amplifier, Conductive

Model: SV 115 724

Supply Voltage: 24 VDC

Output Rated Insulation Voltage: SPDT relay 250 VAC (rms)

Mechanical Life: ≥ 5 x 10 7 operations

Electrical Life: ≥10 5 operations

Operation Frequency: ≤ 7200 operations/h

Contact Ratings: Resistive loads: AC 1 10 A/250 VAC (2500 VAC)

DC 1 1 A/250 VAC (250 W)

Small inductive loads: AC 15 2.5 A/230 VAC

DC 13 5 A/24 VDC

Degree of Protection: IP 20

Sensitivity: 3.5 … 25 kΩ

Operating Temperature: -20 … +50 °C

Pollution Degree: 3

Dimensions: 34 X 91 X 79.8 mm

Weight: 0.11 Kg
