Carlo Gavazzi SV 225 230 Conductive Sensors Amplifier

Manufacturer: CARLO GAVAZZI

Type: Conductive Sensors Amplifier

Model: SV 225 230

Supply Voltage: 230 VAC

Frequency: 50/60 Hz

Mechanical Life: ≥ 5 x 10⁷ operations

Electrical Life: ≥105 operations

Operation Frequency: ≤ 7200 operations/h

Contact Rating:

• AC 1: 250 VAC, 8 A
• AC 11: 230 VAC, 2.5 A
• DC 1: 250 VDC, 0.4 A
• DC 11 24 VDC, 5 A

Resistance Range: 3.5 … 25 kΩ

Protection Class: IP 20

Dimensions: 34.5 X 75 X 80 mm

Weight: 0.19 Kg
