Carlo Gavazzi SY 175 380 Time Delay Relay

Manufacturer: Carlo Gavazzi

Type: Time Delay Relay

Model: SY 175 380



Supply voltage: 220/380 V AC -3 phase

Frequency: 50 Hz

Rated operational power: 3 VA

Rated impulse withstand voltage: 4 kV

Adjustable time delay on release: 0.2 … 10s

Output

SPDT relay

Rated insulation voltage: 250 V AC

Contact rating

AC-15: 230 V AC, 2.5 A

DC-13: 24 V DC, 5 A



Degree of protection: IP20

Operation temperature: -20 … +50°C

Dimension: 114 x 22.5 x 96.5 mm
