Contrel Elettronica ELRC-1 Earth-Leakage Protection Relay
New
In stock1 unitReady to ship
Earth-Leakage Differential Protection Relay
The Contrel Elettronica ELRC1 relay offers adjustable tripping current from 0.25 A to 2.5 A and is designed for panel-mount or DIN rail installation. It operates across a range of auxiliary voltages, providing effective protection for electrical systems.1“10220380ACAc/DcAdjustablecomasContrelCurrentdifferentialDINEarthElectricalElettronicaELRC1LeakagemountPanelProtectionrailRelaySystemTrippingV
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Contrel Elettronica ELRC1 “ Earth-Leakage Differential Protection Relay
The Contrel Elettronica ELRC1 is a high-quality earth-leakage differential protection relay, designed to safeguard electrical systems from leakage currents. With flexible auxiliary voltage options and adjustable tripping current settings, it ensures reliable protection and performance in diverse applications.
Manufacturer: Contrel Elettronica
Type: Earth-Leakage Differential Protection Relay
Model: ELRC1
Ref. No.: 08 94
| Auxiliary Voltage | 110 V AC/DC, 220 V AC, 380 V AC |
| Contact Configuration | 1 Change over contact |
| Mounting | Panel-mount, DIN rail |
| Tripping Current | Max. 2.5 A, Min. 0.25 A |
| Setting Time | Max. 0.5 s, Min. 0.02 s |
| Hole Diameter | 80 mm |
