Crouzet F83161.1 Miniature Microswitch
New
Available on request
20,00$
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Manufacturer: CROUZET
Type: MINIATURE MICROSWITCH
Series: 83161
Model: F83161.1 / 83 161 1
Material: Polyamida, AgNi
Levers Material: Stainless steel
No. of Terminals: 3
Min. Rating Current: 0.1 A … 20 A
Nom. Rating Current: 16 A
Voltage: 250 V AC
Max. Operating Force: 3 N
Min. Release Force: 1 N
Max. Total Travel Force: 4.5 mm
Tripping Point: 14.7 mm ± 0.4
Max. Differential Travel: 0.35 mm
Contact Gap: 0.4 mm
Ambient Operating Temperature: -20 … 125°C
Weight: 0.08 kg
