Pressure Switches

Danfoss MBS 3000 Pressure Transmitter 1 BAR

Name: DANFOSS MBS 3000 PRESSURE TRANSMITTER 1 BAR
SKU: 994282
Availability: LimitedAvailability

danfoss-MBS-3000-1-bar-pressure-transmitter

danfoss-mbs-3000-1-bar-pressure-transmitter-2

danfoss-mbs-3000-1-bar-pressure-transmitter-3

danfoss-mbs-3000-1-bar-pressure-transmitter-4

danfoss-mbs-3000-1-bar-pressure-transmitter-5

Used

Available on request

Pressure Transmitter

The DANFOSS MBS3000 is a robust pressure transmitter with 0 to 1 bar range, 4 to 20 mA output, 9 to 32 V DC supply, and stainless steel AISI 316L body for demanding hydraulic and industrial environments.

Manufacturer

DANFOSS

SKU

994282

Category

Pressure Switches

Condition

Used

0“6 1/2 20 316L 32 4 80 9 98 Aisi Danfoss dc G Hydraulic Industrial mA MBS3000 Output Pressure Sensor stainless Steel to Transmitter V

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

DANFOSS MBS3000 Pressure Transmitter

The DANFOSS MBS3000 Pressure Transmitter is engineered for precise pressure measurement in industrial and hydraulic applications. It offers excellent resistance to cavitation, liquid hammer, and pressure peaks, ensuring long-term stability and reliability even in harsh operating conditions.

Manufacturer: DANFOSS

Type: Pressure Transmitter

Model: MBS3000

Part Number: 98 98 80 06

Pressure Measuring Range	0 to 1 bar
Connection	G 1/2, threaded
Electrical Connection	Plug connection
Supply Voltage	9 to 32 V DC
Current Output	4 to 20 mA
Sensor Temperature Range	minus 40 to 85 degree Celsius
Design	Suitable for severe industrial and hydraulic environments
Resistance	Cavitation, liquid hammer, and pressure peaks (MBS 3050)
Enclosure and Wetted Parts	Acid-resistant stainless steel (AISI 316L)
