Dold BD5987.03/001 Safety Gate Relay

Manufacture: Dold
Type: Safety Gate Relay
Model: BD5987.03/001
Art. No.: 0041171

Nominal voltage U_N: 24 V DC
Nominal consumption: 4 VA
Contact rating: 2 NO contacts, 1 NO contact used for monitoring
Switching capacity:
AC-15: 250 V AC,5 A
Monitoring contact: 0,1 … 1 A / 10 …120 V AC/DC
Operation temperature: -15 … 55°C
Degree of protection: Housing: IP 40, Terminals: IP 20
Housing: Thermoplastic with V0 behavior
Mounting: DIN rail
Dimensions: 45 x 74 x 121 mm
