Eliwell IC 912 Single Stage Controller FOR Temperature

Manufacturer: eliwell

Type: Single Stage Controller for Temperature

Model: IC912

Part No.: IP11A00TRD400

Mounting: panel mounting, cut out 29×71 mm(+0.2/–0.1mm)

Usage Temperature: -5 … 55°C

Serial: TTL port for Copy Card

Display: 3½ digits plus sign

Precision: above 0.5% of bottom scale + 1 digit

Consumption: 3 VA (115/230 V model), 1.5 VA (12 V model)

Resolution: 1°C or 0.1°C (selectable with a parameter)

Connections: screw terminals for <2.5mm²
Power Supply: 230, 115, 24 VAC, 12 VAC

Frequency: 50/60 Hz

Container: plastic resin PC+ABS UL94V–0, polycarbonate glass, thermoplastic resin keys

Frontal Protection: IP 65

Dimensions: 32 X 74 X 60 mm

Weight: 0.14 Kg
