Endress+Hauser 11375Z-RXG1A1A3 ROD Probe

Endress+Hauser Rod Probe 11375ZRXG1A1A3

Manufacturer: Endress+Hauser

Type: Rod Probe

Model: 11375ZRXG1A1A3

Part No.: 250001887 A

The Endress+Hauser Rod Probe 11375ZRXG1A1A3 is engineered to provide reliable point level detection in liquid applications, including overfill protection, pump protection, and two-point control. Designed for harsh industrial environments, this rod probe offers robust performance with Ex-area Zone 0 compatibility.

Application:

• As overfill protection with line monitoring even in Ex-area Zone 0
• For minimum or maximum detection in tanks
• As pump protection in pipes
• Can be used for two-point control

Technical Specifications:

• Process Temperature: -40 / +135 °C
• Process Pressure: Up to 50 bar
• Minimum Conductivity of Medium: 20 µS/cm
• Measuring Range: 50 / 2000 mm
• Length of Probe: 500 mm
• Probe Diameter: 8 mm
• Process Connection, Material: Thread ISO228 G ½ A, 316Ti
• Partial Insulation Material, Diameter: PTFE, 20 mm
• Rod Material: 316Ti

With its wide temperature and pressure ranges, the Endress+Hauser 11375ZRXG1A1A3 rod probe is ideal for industries where safety and precise level measurement are critical. Its compatibility with hazardous zones, alongside its rugged design, ensures secure operation and long service life in demanding applications.
