Epcos B25834-F6104-M001 Film Capacitor
New
In stock1 unitReady to ship
Film AC Capacitor
Epcos B25834F6104M001, 0.10 µF, 900 V AC rated, stud connection, oil-impregnated plastic film with self-healing design, compliant with IEC 61071-1.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Epcos B25834F6104M001 Film AC Capacitor
The Epcos B25834F6104M001 is a high-quality film AC capacitor designed for demanding AC applications, ensuring stable performance, low losses, and long service life. Built with oil-impregnated tubular windings and a self-healing design, it meets IEC 61071-1 standards for industrial reliability.
Manufacturer: Epcos
Type: Film AC Capacitor
Model: B25834F6104M001
Ref. No.: 12.11 / SH
| Capacitance | 0.10 µF (100 nF) |
| Tolerance | ± 20% |
| Rated Nominal Voltage | 900 V AC |
| Rated Insulation Voltage | 780 V AC |
| Operating Temperature Range | -25 to +85 °C |
| Termination Style | Stud (threaded) connection |
| Dielectric Material | Plastic film, oil-impregnated tubular windings, self-healing design |
| Standard | IEC 61071-1 |
