Fafnir 2MM9107WIUL Super Precision Angular Contact Ball Bearing
New
Available on request
Angular Contact Ball Bearing
High-precision Fafnir / Timken spindle angular contact ball bearing with 15° contact angle, ISO P4S accuracy, and duplex mounting for high-speed machine tool applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Fafnir / Timken 2MM9107WI UL Spindle Angular Contact Ball Bearing
The Fafnir / Timken 2MM9107WI UL is a high-precision spindle angular contact ball bearing designed for high-speed and high-accuracy machine tool applications. It is supplied as a matched set for duplex mounting, ensuring optimal stiffness, accuracy, and thermal stability.
Manufacturer: Fafnir / Timken
Type: Spindle Angular Contact Ball Bearing
Model: 2MM9107WI UL
| Bore Diameter (d) | 35 mm |
| Outer Diameter (D) | 62 mm |
| Total Width (B) | 28 mm |
| Contact Angle | 15° |
| Mounting | Duplex Pairs of Bearings |
| Dynamic Load Rating (Cr) | 21,200 N |
| Static Load Rating (C0r) | 13,700 N |
| Operating Speed (Grease) | 22,600 rpm |
| Operating Speed (Oil) | 45,200 rpm |
| Preload | Light |
| Precision Rating | ISO P4S (ABEC 7 / 9) |
| Cage | MBR |
| Number of Items per Set | 2 |
