FAG 1208K.TV.C3 Self-Aligning Ball Bearing
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The FAG 1208K.TV.C3 self-aligning ball bearing features a 40 mm bore diameter, 80 mm outer diameter, and a glass-fiber reinforced cage, providing superior load capacity and misalignment compensation.1208K.TV.C34080BallbearingboreC3CageClearancediameterFagHighLoadmmOuterPA66PrecisionradialSelf-Aligningtapered
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1208K.TV.C3 Self-Aligning Ball Bearing
The FAG 1208K.TV.C3 Self-Aligning Ball Bearing is designed for applications requiring high radial load capacity and misalignment compensation. With a solid glass-fiber reinforced polyamide cage and a tapered bore, this bearing provides durability and reliability in demanding conditions.
Manufacturer: FAG
Type: SELF-ALIGNING BALL BEARING
Model: 1208K.TV.C3
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 80 mm |
| Width (B) | 18 mm |
| Dynamic Load Rating (Cr) | 19,400 N |
| Static Load Rating (C0r) | 6,500 N |
| Fatigue Load Rating | 415 N |
| Limiting Speed | 10,100 rpm |
| Reference Speed | 8,600 rpm |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
| Bore Type | K, Tapered, taper 1:12 |
| Radial Internal Clearance | C3 |
