FAG 1210K.TV.C3 Self-Aligning Ball Bearing
The FAG 1210K.TV.C3 Self-Aligning Ball Bearing is designed to accommodate misalignment while maintaining smooth and efficient operation. Featuring a tapered bore and a high-performance polyamide cage, this bearing is ideal for applications requiring enhanced durability and reliability.
Manufacturer: FAG
Type: SELF-ALIGNING BALL BEARING
Model: 1210K.TV.C3
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 90 mm |
| Width (B) | 20 mm |
| Dynamic Load Rating (Cr) | 22,900 N |
| Static Load Rating (C0r) | 8,100 N |
| Fatigue Load Rating | 520 N |
| Limiting Speed | 8,700 rpm |
| Reference Speed | 7,700 rpm |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
| Bore Type | K, Tapered, taper 1:12 |
| Radial Internal Clearance | C3 |
