FAG 1309 TV Self-Aligning Ball Bearing
New
In stock2 unitsReady to ship
Self-Aligning Ball Bearing
The FAG 1309 TV self-aligning ball bearing features a 45 mm bore diameter, 100 mm outer diameter, and polyamide PA66 cage, ensuring durability and smooth alignment under high loads.100130945BallbearingboreCageCapacityCompensationdiameterFagGlass-FiberHighIndustrialLoadMisalignmentmmOuterPA66reinforcedSelf-AligningTV
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1309 TV Self-Aligning Ball Bearing
The FAG 1309 TV Self-Aligning Ball Bearing is engineered for applications requiring high load capacity and alignment flexibility. Designed with a glass-fiber reinforced polyamide cage, this bearing ensures durability and smooth operation under dynamic and static loads.
Manufacturer: FAG
Type: SELF-ALIGNING BALL BEARING
Model: 1309 TV
This self-aligning ball bearing is designed to compensate for shaft misalignments, offering smooth operation, enhanced durability, and a long service life in various industrial applications.
| Bore Diameter (d) | 45 mm |
| Outer Diameter (D) | 100 mm |
| Width | 25 mm |
| Dynamic Load Rating | 38500 N |
| Static Load Rating | 12700 N |
| Fatigue Load Limit | 810 N |
| Limiting Speed | 7500 RPM |
| Reference Speed | 6700 RPM |
| Cage | TV, Solid cage made of glass-fiber reinforced polyamide PA66 |
