FAG 1310TV.C3 Self-Aligning Ball Bearing
New
In stock8 unitsReady to ship
Self-Aligning Ball Bearing
The FAG 1310TV.C3 bearing features a 50 mm bore, 110 mm outer diameter, and C3 clearance. Built with a glass-fiber reinforced PA66 cage, it supports misalignment and operates at speeds up to 6,900 rpm.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1310TV.C3 Self-Aligning Ball Bearing
The FAG 1310TV.C3 Self-Aligning Ball Bearing is designed to accommodate misalignment and minimize friction in dynamic applications. With a C3 clearance and TV solid cage made of PA66, it offers reduced maintenance, high-speed capabilities, and excellent load capacity, making it ideal for challenging industrial environments.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 1310TV.C3
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 110 mm |
| Width (B) | 27 mm |
| Dynamic Load Rating | 42,000 N |
| Static Load Rating | 14,200 N |
| Fatigue Load Limit | 900 N |
| Limiting Speed | 6,900 1/min |
| Reference Speed | 6,300 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
| Clearance | C3 |
