FAG 2202TV Self-Aligning Ball Bearing
New
In stock2 unitsReady to ship
Self-Aligning Ball Bearing
FAG 2202TV Self-Aligning Ball Bearing features a 15 mm bore diameter and 35 mm outer diameter. It supports dynamic loads up to 9,600 N and operates at speeds up to 22,200 1/min with a glass-fiber reinforced polyamide cage.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 2202TV Self-Aligning Ball Bearing
The FAG Self-Aligning Ball Bearing 2202TV is designed to support both radial and axial loads while providing self-aligning capabilities. With a dynamic load rating of 9,600 N and a solid polyamide cage, this bearing is ideal for high-speed and high-performance applications.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 2202TV
| Bore Diameter (d) | 15 mm |
| Outer Diameter (D) | 35 mm |
| Width (B) | 14 mm |
| Dynamic Load Rating (Cr) | 9,600 N |
| Static Load Rating (C0r) | 2,100 N |
| Fatigue Load Limit | 133 N |
| Limiting Speed | 22,200 1/min |
| Reference Speed | 19,600 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
