FAG 22214E1 Spherical Roller Bearing
Manufacturer: Schaeffler FAG
Type: Spherical Roller Bearing
Model: 22214 E1
Replaces: 22214-E1-XL, 22214-E1
Dimensions:
Bore Diameter d: 70 mm
Outer diameter D: 125 mm
Width: 31 mm
Dynamic load rating: 211000 N
Static load rating: 226000 N
Fatigue load limit: 28500 N
limiting speed: 6700 RPM
Reference speed: 3950 RPM
Cage material: Sheet metal cage
Operating temperature: -30 … +200 °C
